What's new in Kwant 1.3
=======================
This article explains the user-visible changes in Kwant 1.3.0,
released on 19 May 2017.
See also the `full list of changes up to the most recent bugfix
release of the 1.3 series
`_.
Using high-symmetry builders as models
--------------------------------------
Builders now have a `~kwant.builder.Builder.fill` method that fills a builder
instance with copies of a template builder. This can be used to "cut out"
shapes from high-symmetry models, or to increase the symmetry period of a lead.
Thus Kwant gains the new concept of a "model". Models may be created manually,
or with the new function `kwant.continuum.discretize` (see next paragraph).
There is also support for finalizing models and e.g. calculating their band
structure (see `Finalizing builders with multiple translational symmetries`_).
Tools for continuum Hamiltonians
--------------------------------
The new sub-package `~kwant.continuum` is a collection of tools for working
with continuum models and for discretizing them into tight-binding models. It
aims at providing a handy interface to convert symbolic Hamiltonians into a
builder with N-D translational symmetry that can be use to calculate
tight-binding band structures or construct systems with different/lower
symmetry. For example in just a few lines we can construct a two-band model that exhibits
a quantum anomalous spin Hall phase:
.. literalinclude:: ../../code/include/plot_qahe.py
:start-after: HIDDEN_BEGIN_model
:end-before: HIDDEN_END_model
From: :download:`QAHE example script <../../code/download/plot_qahe.py>`
See the tutorial: :doc:`../../tutorial/discretize`
See the reference documentation: :doc:`../../reference/kwant.continuum`
Calculating charges and currents using the operator module
----------------------------------------------------------
Often one may wish to calculate quantities that are defined over sites of
the system (such as charge density, spin density along some axis etc),
or over hoppings of the system (such as current or spin current). With
the introduction of the ``operator`` module it has now become much easier
to calculate such quantities. To obtain the regular density and current
everywhere in a system due to a wavefunction ``psi``, one only needs to do
the following::
syst = make_system().finalized()
psi = kwant.wave_function(syst)(0)[0]
# create the operators
Q = kwant.operator.Density(syst)
J = kwant.operator.Current(syst)
# evaluate the expectation value with the wavefunction
q = Q(psi)
j = J(psi)
See the tutorial: :doc:`../../tutorial/operators`
Plotting of currents
--------------------
Quantities defined on system hoppings (e.g. currents calculated using
`~kwant.operator.Current`) can be directly plotted as a streamplot over the
system using `kwant.plotter.current`. This is similar to how
`kwant.plotter.map` can be used to plot quantities defined on sites.
The example below shows edge states of a quantum anomalous Hall phase
of the two-band model shown in the `above section
<#tools-for-continuum-hamiltonians>`_:
.. literalinclude:: ../../code/include/plot_qahe.py
:start-after: HIDDEN_BEGIN_current
:end-before: HIDDEN_END_current
.. image:: ../../code/figure/plot_qahe_current.*
From: :download:`QAHE example script <../../code/download/plot_qahe.py>`
Scattering states with discrete symmetries and conservation laws
----------------------------------------------------------------
Given a lead Hamiltonian that has a conservation law, it is now possible to
construct lead modes that have definite values of the conservation law. This
is done by declaring projectors that block diagonalize the Hamiltonian before
the modes are computed. For a Hamiltonian that has one or more of the three
fundamental discrete symmetries (time-reversal symmetry, particle-hole symmetry
and chiral symmetry), it is now possible to declare the symmetries in Kwant.
The symmetries are then used to construct scattering states that are properly
related by symmetry. The discrete symmetries may be combined with conservation
laws, such that if different blocks of the Hamiltonian are related by a discrete
symmetry, the lead modes are computed to reflect this.
See the updated tutorial: :doc:`../../tutorial/superconductors`
Named parameters for value functions
------------------------------------
In Kwant < 1.3 whenever Hamiltonian values were provided as functions,
they all had to take the same extra parameters (after the site(s))
regardless of whether or not they actually used them at all. For example,
if we had some onsite potential and a magnetic field that we
model using the Peierls substitution, we would have to define our value
functions like so::
# formally depends on 'B', but 'B' is never used
def onsite(site, V, B):
return V
# formally depends on 'V', but 'V' is never used
def hopping(site_a, site_b, V, B):
return (site_b.pos[1] - site_a.pos[1]) * B
This was because previously extra arguments were provided to the system
by passing them as a sequence via the ``args`` parameter to various Kwant
functions (e.g. ``kwant.smatrix`` or ``hamiltonian_submatrix``).
In Kwant 1.3 it is now possible for value functions to depend on different
parameters, e.g.::
def onsite(site, V):
return V
def hopping(site_a, site_b, B):
return (site_b.pos[1] - site_a.pos[1]) * B
If you make use of this feature then you must in addition pass your arguments
via the ``params`` parameter. The value provided to ``params`` must
be a ``dict`` that maps parameter names to values, e.g.::
kwant.smatrix(syst, params=dict(B=0.1, V=2))
as opposed to the old way::
kwant.smatrix(syst, args=(2, 0.1))
Passing a dictionary of parameters via ``params`` is now the recommended way
to provide parameters to the system.
Reference implementation of the kernel polynomial method
--------------------------------------------------------
The kernel polynomial method is now implemented within Kwant to obtain the
density of states or, more generally, the spectral density of a given operator
acting on a system or Hamiltonian.
See the tutorial: :doc:`../../tutorial/kpm`
See the reference documentation: :doc:`../../reference/kwant.kpm`
Finalizing builders with multiple translational symmetries
----------------------------------------------------------
While it remains impossible to finalize a builder with more than a single
direction of translational symmetry, the ``wraparound`` module has been added
as a temporary work-around until the above limitation gets lifted.
The function `~kwant.wraparound.wraparound` transforms all (or all but one)
translational symmetries of a given builder into named momentum parameters
`k_x`, `k_y`, etc. This makes it easy to compute transport through systems
with periodic boundary conditions or across infinite planes.
Plotting the 2-d band structure of graphene is now as straightforward as::
from matplotlib import pyplot
import kwant
lat = kwant.lattice.honeycomb()
sym = kwant.TranslationalSymmetry(lat.vec((1, 0)), lat.vec((0, 1)))
bulk = kwant.Builder(sym)
bulk[ [lat.a(0, 0), lat.b(0, 0)] ] = 0
bulk[lat.neighbors()] = 1
wrapped = kwant.wraparound.wraparound(bulk).finalized()
kwant.wraparound.plot_2d_bands(wrapped)
Consistent ordering of sites in finalized builders
--------------------------------------------------
In Python 3 the internal ordering of dictionaries is not deterministic. This
meant that running a Kwant script twice would produce systems with different
ordering of sites, which leads to non-reproducible calculations. Now, sites
in finalized builders are always ordered first by their site family, then by
their tag.
Coincidentally, this means that you can plot a wavefunction in a simple 1D
system by just saying::
lattice_1D = chain()
syst = make_system(lattice_1D)
h = syst.hamiltonian_submatrix()
pyplot.plot(np.eigs(h)[1][0])
attach_lead() can now handle leads with greater than nearest-neighbor hoppings
------------------------------------------------------------------------------
When attaching a lead with greater than nearest-neighbor hoppings, the symmetry
period of the finalized lead is suitably extended and the unit cell size is
increased.
Pickling support
----------------
It is now possible to pickle and unpickle `~kwant.builder.Builder` and
`~kwant.system.System` instances.
Improved build configuration
----------------------------
The name of the build configuration file, ``build.conf`` by default, is now
configurable with the ``--configfile=PATH`` option to ``setup.py``. (This
makes build configuration usable with the ``pip`` tool.) The build
configuration as specified in this file is now more general, allowing to
modify any build parameter for any of the compiled extensions contained in
Kwant. See the :ref:`Installation instructions ` for
details.
Builder.neighbors() respects symmetries
---------------------------------------
Given a site, the method `~kwant.builder.Builder.neighbors` of
`~kwant.builder.Builder` returns an iterator over sites that are connected by a
hopping to the provided site. This is in contrast to previous versions of
Kwant, where the neighbors were yielded not of the provided site, but of it's
image in the fundamental domain.
This change is documented here for completeness. We expect that the vast
majority of users of Kwant will not be affected by it.
